IT40SW1 WIRELESS LAN TOWER LIGHT

IT40SW1 Tower Light Series

WIRELESS LAN TOWER LIGHT
(small size, 40 mm dia., Modbus/TCP, 1 - 5 layers, bridge)

Functions & Features
• Lighting, blinking and buzzing available with contact input or PC via Modbus/TCP.
• Contact input status acquisition available through wireless LAN.
• Connection to network with bridge function, in remote I/O  Ethernet type via wireless LAN.
• Wireless LAN connection complied with IEEE802.11b/g/n
• Nondirectional antenna (360°horizontal)

MODEL: IT40SW1-[1][2][3][4][5][6]D2-R[7]

ORDERING INFORMATION
• Code number: IT40SW1-[1][2][3][4][5][6]D2-R[7]
Specify a code from below for each [1] through [7].
 (e.g. IT40SW1-5RYGBWD2-R/Q)
• Specify the specification for option code /Q
 (e.g. /C01)

[1] LAMP LAYERS
1: 1 layer
2: 2 layers
3: 3 layers
4: 4 layers
5: 5 layers

[2] LAMP 1 COLOR
(1st layer from the top)
R: Red
Y: Amber
G: Green
B: Blue
W: White

[3] LAMP 2 COLOR
(2nd layer from the top)
R: Red
Y: Amber
G: Green
B: Blue
W: White
N: None (not available when Lamp Layers selected are 2 - 5)

[4] LAMP 3 COLOR
(3rd layer from the top)
R: Red
Y: Amber
G: Green
B: Blue
W: White
N: None (not available when Lamp Layers selected are 3 - 5)

[5] LAMP 4 COLOR
(4th layer from the top)
R: Red
Y: Amber
G: Green
B: Blue
W: White
N: None (not available when Lamp Layers selected are 4 - 5)

[6] LAMP 5 COLOR
R: Red
Y: Amber
G: Green
B: Blue
W: White
N: None (not available when Lamp Layers selected are 5)
* The selection of the same color for more than one layer is not available.
* Select "None" option for the layers other than the selected.

MOUNTING
D: Direct mounting

DESIGN TYPE
2: Type 2
(refer to outline dimensions)

POWER INPUT
DC Power
R: 24 V DC
(Operational voltage range 24 V ±10 %, ripple 10 %p-p max.)

COUNTRY
blank: Japan, EU

[7] OPTIONS
blank: none
/Q: With options (specify the specification)

SPECIFICATIONS OF OPTION: Q
COATING (For the detail, refer to M-System's web site.)
/C01: Silicone coating
/C02: Polyurethane coating
/C03: Rubber coating

RELATED PRODUCTS
• LAN cable (model: ITCA)
• Mounting Pole (model: ITPL)
• Mounting Adapter (model: ITAD1)
• PC configurator software (model: ITCFG)
Functions are configurable using the PC Configurator Software.
Downloadable at M-System’s web site.
