MULTI POWER TRANSDUCER M5XWT

M5XWT

Super-mini Terminal Block Signal Conditioners M5X-UNIT

MULTI POWER TRANSDUCER

(self-powered, PC programmable)
Functions & Features
• Super-mini power transmitter
• 5 to 600 A clamp CT use for current sensor
• Single-phase/2-wire, single-phase/3-wire and 3-phase/3-wire are available
• High-density mounting
• Power LED
• No auxiliary power source required

MODEL: M5XWT-113[1]

ORDERING INFORMATION

• Code number: M5XWT-113[1]
Specify a code from below for [1].
  (e.g. M5XWT-113/Q)
• Specify the specification for option code /Q
  (e.g. /C01/S01/SET)

CONFIGURATION

1: Single phase / 2-wire and 3-wire, 3-phase / 3-wire

INPUT

1: 240 V AC / CLSE
Clamp-on current sensor is selectable from below.
CLSE (5A, 50A, 100A, 200A, 400A, 600A)
5A is available as CT's secondary.

EXTERNAL INTERFACE

3: Modbus communication

[1] OPTIONS

blank: none
/Q: With options (specify the specification)

SPECIFICATIONS OF OPTION: Q (multiple selections)

COATING (For the detail, refer to our web site.)
/C01: Silicone coating
/C02: Polyurethane coating
/C03: Rubber coating
TERMINAL SCREW MATERIAL
/S01: Stainless steel
EX-FACTORY SETTING
/SET: Preset according to the Ordering Information Sheet
 (No. ESU-2782)

RELATED PRODUCTS

• PC Configurator cable (model: COP-US)
• PC configurator software (model: PMCFG)
Downloadable at our web site.
• Clamp-on current sensor (model: CLSE)

GENERAL SPECIFICATIONS

Construction: Terminal block
Connection: M3.5 screw terminals (torque 0.8 N·m)
Screw terminal: Nickel-plated steel (standard) or stainless steel
Housing material: Flame-resistant resin (black)
Isolation: Current input or voltage input to Modbus
Measured variables
  Voltage: R-S, S-T, T-R
  Current: R, S, T
  Active power
  Reactive power
  Apparent power
  Power factor
  Frequency
  Active energy: Incoming / outgoing
  Reactive energy: Incoming / outgoing / lag (inductive)
  /lead (capacitive)
  Apparent energy
  Average active power (demand)
  Average reactive power (demand)
  Average apparent power (demand)
  Average (demand) current: R, S, T
  Max. and min. values
  Simplified measurement mode: Calculates power from current values with fixed voltage values and power factor.
Power indicator LED: Green LED; Blinking patterns indicate different operating status of the transmitter.

MODBUS COMMUNICATION

Communication: Half-duplex, asynchronous, no procedure
Standard: Conforms to TIA/EIA-485-A
Transmission distance: 500 meters max.
Baud rate: 1200, 2400, 4800, 9600, 19200, 38400 bps (default: 38400 bps)
Protocol: Modbus RTU
Node address: 1 to 247 (default: 1)
Parity: None, even or odd (default: odd)
Stop bit: 1 or 2 (default: 1)
Max. number of nodes: 31 (excluding master)
Transmission media: Shielded twisted-pair cable
(CPEV-S 0.9 dia.)
Internal terminating resistor: 110 Ω

INPUT SPECIFICATIONS

Frequency: 50 / 60 Hz (45 – 66 Hz)
• Voltage Input
Rated voltage: 240 V AC
Input range: 80 - 260 V AC
(Phase voltage range is 80 - 130 V for single-phase/3-wire)
Consumption VA:
• P1 - P2: ≤ 3 VA (power consumption of internal circuit)
• P2 - P3: voltage2/≤ 1. 5MΩ VA
Selectable primary voltage range: 50 – 400 000 V
• Current Input
CLSE-R5: 0 – 5 A AC
CLSE-05: 0 – 50 A AC
CLSE-10: 0 – 100 A AC
CLSE-20: 0 – 200 A AC
CLSE-40: 0 – 400 A AC
CLSE-60: 0 – 600 A AC
Input range: 0 - 120 % of the rating
Low-end cutout (current): 0 - 99.9 % (default setting: 1 %)
Selectable primary current range: 1 – 20 000 A (only with CLSE-R5, refer to the configurator settings)

INSTALLATION

Operating temperature: -20 to +65°C (-4 to +149°F)
Operating humidity: 30 to 90 %RH (non-condensing)
Atmosphere: No corrosive gas or heavy dust
Mounting: DIN rail
Weight: 80 g (2.8 oz)

PERFORMANCE

Input Accuracy*1
  Voltage: ±0.5 %*2
  Current: ±0.5 %*2
  Power: ±0.5 %*2
  Power factor: ±1.5 %
  Frequency: ±0.5 Hz
  Energy: ±2 % (power factor ≥ 0.5, input ≥ 10 %)
*1. Sensor error margin not included. Add sensor error margin when using with the combination of the sensor.
*2. An accuracy for rated input. The described accuracy levels are ensured at the input 1 % or more for neutral current in a single-phase/3-wire circuit and phase-S current in an 3-phase/3-wire circuit.
Temp. coefficient: ±0.0075 %/°C (0.004 %/°F)
Sampling time: ≤ 500 msec.
Insulation resistance: ≥ 100 MΩ with 500 V DC
Dielectric strength: 2000 V AC @ 1 minute
(current input or voltage input to Modbus to ground)

--------------------
