MAT3 LIGHTNING SURGE PROTECTOR FOR THREE-PHASE POWER SUPPLY

Liên hệ Còn hàng

MAT3

Lightning Surge Protectors for
Electronics Equipment M-RESTER

LIGHTNING SURGE PROTECTOR
FOR THREE-PHASE POWER SUPPLY

Functions & Features
• Connected in parallel between the power and earth lines regardless of load current
• Applicable to single phase 2/3-wire and threephase 3/4-wire system
• High discharge current capacity 20 kA or 40 kA (8/20 μs)
• Degraded head element is automatically separated from the power lines by the incorporated thermal breaker, and the LED lamp (turns off) and the relay contact alerts the failure status.
• Complies with IEC 61643-11 Class II
Typical Applications
• Low-voltage distribution board
• Combination with installation for large load current


MODEL: MAT3–240[1]M[2]

ORDERING INFORMATION

• Code number: MAT3-240[1]M[2]
Specify a code from below for each of [1] and [2].
  (e.g. MAT3-2403MY)

OPERATIONAL VOLTAGE

240: 240 V AC

[1] POWER SYSTEM

3: Single-phase 2/3-wire, Three-phase 3-wire
4: Single-phase 2/3-wire, Three-phase 3/4-wire

MAXIMUM DISCHARGE CURRENT

M: 20kA (8/20 μsec.)

[2] ALARM OUTPUT

A: With
Y: Without

GENERAL SPECIFICATIONS

Construction: Standalone; terminal access at the front
Degree of protection: IP20 (If the solderless terminals are covered with insulation tubes.)
Surge protection type: Voltage limiting type one-port SPD
Connection
  Line: M5 screw terminal (torque: 2.5 N·m)
  Alarm output: Tension clamp
Applicable wire size
 Line: See the drawing below.
 Alarm output: 0.13 to 1.5 mm2, stripped length 8 mm
Screw terminal
 Line
: Nickel-plated steel
 Alarm output: Tin-plated copper alloy
Housing material: Flame-resistant resin (black)
Alarm output: SPDT relay contact trips when the thermal breaker operates.
OUTPUT TERMINAL A1 – C
Normal: Open
Failure or power off: Close
OUTPUT TERMINAL A2 – C
Normal: Close
Failure or power off: Open
Rated load:
250 V AC @1 A (resistive load)
24 V DC @1 A (resistive load)
Safety function: Thermal breaker incorporated
Monitor LED: Green LED turns on during normal condition and turns off during failure condition, power off or the thermal breaker operating.

INSTALLATION

Operating temperature: -5 to +55°C (23 to 131°F)
Operating humidity: 5 to 95 %RH (non-condensing)
Mounting: DIN Rail
Weight: 300 g (0.66 lb)

PERFORMANCE

Response time: ≤ 3 nanoseconds (≤ 20 nanoseconds for N to PE)
Insulation resistance: ≥ 100 MΩ with 500 V DC (line to alarm output)
Dielectric strength: 2000 V AC @1 minute (line to alarm output)
Surge protection: IEC 61643-11 Class II
                             EN 61643-11 Class II

STANDARDS & APPROVALS

EU conformity:
Low Voltage Directive
  EN 61643-11
RoHS Directive

CONNECTION EXAMPLES

EXTERNAL DIMENSIONS & TERMINAL ASSIGNMENTS unit: mm [inch]

SCHEMATIC CIRCUITRY

--------------------
