REA Multiple Rotary Electrical Actuator

REA Multiple Rotary Electrical Actuator

Valve Specific Information

SpecificationTorque range: 10Nm-32,000 Nm

Output speed: 4-180 rpm

The Limit and Torque Stop Output in according to ISO standards

Used for three phase AC motors, single-phase

AC motor and DC motor

Handwheel for manual operation

External conditions:

High cabinet seal protection level

High corrosion-proof grade

Different temperature will be used

Options:

Middle position switch

Ganged switch

The remote location transmitter

Permanent magnet limit & torque transmitter MWG

Mechanical position indicator
