SWING CHECK VALVE - DKM

SWING CHECK VALVE

DESCRIPTION

prevent reversal of flow through pipe lines. the swing check valve uses a hinged door to open during flow and to close against a pressure reversal. most dong-kang swing check valves can be installed in horizontal or vertical upward flow piping. they offer low resistance to flow and are particularly suited to low velocity service.



CLASS

API 800, 1500
ANSI 150, 300, 600, 900, 2500, 4500



SIZE

3/8" , 1/2" , 3/4" , 1" , 1 1/4" , 1 1/2" , 2"



MATERIAL

ASTM A105, A182-F5, A182-F9, A182-F11, A182-F22, A182-F304, A182-F316,
A182-F304L, A182-F316L, A182-F321, A182-F347, A182-F51, A182-F91, A350-LF2



Other Materials also Available on Application



END CONNECTION

SOCKET WELDING, THREADED BUTT WELDING, FLANGED



FEATURE

BOLTED COVER OR WELDED COVER RENEWABLE SEAT
