UNIVERSAL TEMPERATURE TRANSMITTER Model: 27HU

2-WIRE UNIVERSAL TEMPERATURE TRANSMITTER

Model: 27HU

2-WIRE UNIVERSAL TEMPERATURE TRANSMITTER

Model: 27HU - 1

Functions & Features
• Universal input: DC mV, T/C, RTD and resistance
• High accuracy
• HART communication
• Intrinsically safe approval
• Suitable for Functional Safety applications up to SIL2
• Programming via hand-held communicator or via PC
• A wide variety of T/C and RTD types
• User’s temperature table can be used
• Self diagnostics
• Ultra-low temp. drift option (20 ppm/°C typ.)
• CE marking (conforms to ATEX and EMC)

MODEL: 27HU–[1][2]

[1] SAFETY APPROVAL
0: None
1: FM intrinsically safe
2: CENELEC intrinsic safety (ATEX)

[2] OPTIONS
Temperature Drift
Blank: Standard (temp. coefficient 0.015%/°C)
/L: Ultra-low temperature drift
 (temp. coefficient 0.002%/°C typ., 0.005%/°C max.)

2-WIRE UNIVERSAL TEMPERATURE TRANSMITTER Model: 27HU

-------------------------------------
