M1EXT T/C input, 2-channel, PC programmable, with OEL display

Liên hệ Còn hàng
M1EXT Model
  • K, E, J, T, B, R, S, C, N, U, L, P selectable
  • Output selectable within 0-20 mA, ±5 V, and ±10 V
  • 100-240 Vac or 24, 110 Vdc powered
  • 2 channels



MODEL: M1EXT
M1EXT SPECIFICATIONS ES-5985 Rev.0 Page 1/9
2 Channel Super-mini Signal Conditioners
with Display M1E Series
THERMOCOUPLE TRANSMITTER
(2 channels, PC programmable)
Functions & Features
• Accepts direct input from a thermocouple and provides a
linearized process signal
• Wide selection of thermocouples
• 2 channels
• Adjustments with the front button
• OEL display with good visibility
Typical Applications
• Small burnout sensing current enables long distance
transmission with minimum offset drifts
• Electric furnace (isolation)
• No burnout type can connect to a single T/C in parallel with a recorder
MODEL: M1EXT-2–[1][2]
ORDERING INFORMATION
• Code number: M1EXT-2-[1][2]
Specify a code from below for each [1] and [2].
(e.g. M1EXT-2-M2/Q)
• Specify the specification for option code /Q
(e.g. /C01/SET)
NO. OF CHANNELS
2: 2 channels
INPUT – Field-selectable Thermocouple
(PR), K (CA), E (CRC), J (IC), T (CC), B (RH), R, S, C (WRe 5-26), N, U, L, P (Platinel II)
OUTPUT – Field-selectable
◆ DC Output
• Current output: 0 - 20 mA DC
• Voltage output: -5 - +5 V DC
• Voltage output: -10 - +10 V DC
[1] POWER INPUT
AC Power
M2: 100 – 240 V AC (Operational voltage range 85 – 264 V, 47 – 66 Hz)
DC Power
R: 24 V DC (Operational voltage range 24 V ±10 %, ripple 10 %p-p max.) P: 110 V DC
(Operational voltage range 85 – 150 V, ripple 10 %p-p max.)
[2] OPTIONS
blank: none
/Q: With options (specify the specification)
SPECIFICATIONS OF OPTION: Q (multiple selections)
COATING (For the detail, refer to M-System's web site.)
/C01: Silicone coating
/C02: Polyurethane coating
/C03: Rubber coating
EX-FACTORY SETTING
/SET: Preset according to the Ordering Information Sheet
(No. ESU-5985)
